| Feature | Details |
| Temperature Control Range | 0-60℃ |
| Dimensions (W x D x H) | 595 * 565 * 1700 mm |
| Inner Container Size (W x D x H) | 515 * 460 * 1120 mm |
| Capacity | 260 liters |
| Light Source | Top-mounted LED lighting panel, infinite dimming capability |
| Illuminance | 0-5000 LX |
| Number of Illumination Layers | 3 layers |
| Temperature Control Accuracy | 0.1℃ |
| Temperature Fluctuation | ±0.5-1.0℃ |
| Humidity Control Range | 50% RH to 95% RH (humidity control is not applicable below 6℃, except for special users) |
| Humidity Control Accuracy | 1% RH |
| Humidity Fluctuation | ±3-5% RH |
| Heating Time | 60 minutes from 10°C to 40°C |
| Cooling Time | 60 minutes from 40°C to 10°C |
| Range of Illumination Adjustment | 0-100% Emax stepless dimming |
| Wind Direction and Speed | Near horizontal, 0.1 m/s to 0.3 m/s |
| Compressor Working Mode | Intermittent operation |
| Disinfection Method | UV disinfection lamp |
| Service Life of LED Lighting Board | 50,000 hours |
| Instrument Operation Mode | Continuous operation throughout the year |
| Power Supply | 50Hz; 220V ±10% |
Plant Growth Chamber
| The new box design incorporates several advanced features to improve the stability and efficiency of the climate chamber. It uses an LED cold light source for illumination, generating minimal heat to maintain a stable internal temperature. The top of the box is equipped with four layers of vertically mounted lighting panels, ensuring uniform lighting distribution and eliminating the previous issue of stronger light on the sides and weaker light in the center. Additionally, the infinite dimming function allows precise control over light intensity by adjusting the current, providing more accurate lighting without changing the number of lamps. The system also includes a circulating air supply that evenly distributes air from each layer through ducts, resolving temperature discrepancies between the upper and lower sections of the chamber. The LED light board mimics natural light, offering a more conducive environment for plant growth, while its long lifespan reduces maintenance needs. Energy efficiency has been significantly improved, with the new design saving over 70% in energy compared to the second-generation incubators. Equipped with international brand compressors and environmentally friendly refrigerants (R134a), the system ensures high efficiency, low energy consumption, and promotes sustainability, making it an ideal solution for long-term, continuous operation. |
